Mikuni VM-30 round-slide carburetor

Mikuni VM-30 round-slide carburetor, 30mm bore, stock jetting.   This is a great carburetor for small to mid-size Hondas, Kawasaki's, Yamahas, Suzukis and other motorcycle brands.

Main jet 250, pilot jet 40, needle jet 159 P-5, jet needle 6F5, throttle cutaway 2.5, air jet 2.0, idle screw position LEFT, air screw position right.

The VM-30 carburetor is available with left side idle screw position only.  See the VM-32 (L or R) or VM-34 (L or R) carburetors if you need idle adjustment screws on either side.

VM30 dimensions: A=40mm, B=93mm, C=137mm, D=58mm.
